Water Bath
Material of Construction : MS with powder coated shaker
Type of Motin : Reciprocal MotionRPM Range : 50 to 150 stocks per minute
Movement : Liner guided mechanical guided system
Sensor : IR Scan Sensor
Process Controller :4.3” TFT Touch Screen
Temprature Controller : PID Control
Range : 5 Degree above ambient to 100 degree
Accuracy : +/- 0.5 degree
Tray : Aluminium anodized finish
Clamps : 250ml clamps 9nos
6 Holes Rectangular
Specification:
- Double walled chamber, Inner SS, Outer M.S. / S.S. with powder coat finish, immersion heater,
thermostat control, Concentric rings, Glass wool insulation. - Temperature Range: 5 Deg C ambient to 90 Deg. C.
- Size: 350 x 250 x 100mm (6 Holes)
- Digital Temp Controller-cum-Indicator
12 Holes Rectangular
Specification:
- Double walled chamber, Inner SS, Outer M.S. / S.S. with powder coat finish, immersion heater,
thermostat control, Concentric rings, Glass wool insulation. - Temperature Range: 5 Deg C ambient to 90 Deg. C.
- Size: 400 x 300 x 100mm (12 Holes)
- Digital Temp Controller-cum-Indicator
